Britain
4.5"/55 (11.4 cm) Mark 8 Mod 0
114 mm/55 (4.5") Mark 8 Mod 1
Pictures

Updated 11 February 2012


4.5"/55 (11.4 cm) Mark 8 Mod 0 on HMS Northumberland D01
Royal Navy Photograph



4.5"/55 (11.4 cm) Mark 8 Mod 0 on HMS St. Albans F83
Royal Navy Photograph


4.5"/55 (11.4 cm) Mark 8 Mod 0 on HMS Avenger F185 in January 1992
U.S. Navy Photograph No. DN-SC-92-04971



Argentine Destroyer Hercules


HMS Daring running propulsion trials in mid 2007
Royal Navy Photograph


4.5"/55 (11.4 cm) Mark 8 Mod 1
Compare this mounting to the Mod 0 shown above
Image copyrighted by BAE Systems


Artist's Conception of Mod 1 Mounting on a Type 45 Destroyer
Image copyrighted by BAE Systems



4.5"/55 Mark 8 Mod 1 on HMS York
Note the muzzle brake
Royal Navy Photograph


4.5"/55 (11.4 cm) HE ER Round
Image copyrighted by BAE Systems
